New approach creates power out of thin WiFi

Researchers at the National University of Singapore (NUS) and the Tohoku University (TU), Japan, are working to make a device near you powered by the WiFi signals that are commonplace in the modern world.

Image via Pixabay.

Wireless networks are everywhere in towns and cities today. They connect a million devices to the Internet, day in, day out. Needless to say, that’s a lot of energy — over the 2.4GHz radio frequency that such networks use — being beamed all around us all the time. New research is working to harness this energy for a useful purpose, such as charging (for now, tiny) devices.

Airdropping charge

“We are surrounded by WiFi signals, but when we are not using them to access the Internet, they are inactive, and this is a huge waste. Our latest result is a step towards turning readily-available 2.4GHz radio waves into a green source of energy, hence reducing the need for batteries to power electronics that we use regularly.”

“In this way, small electric gadgets and sensors can be powered wirelessly by using radio frequency waves as part of the Internet of Things. With the advent of smart homes and cities, our work could give rise to energy-efficient applications in communication, computing, and neuromorphic systems,” said Professor Yang Hyunsoo from the NUS Department of Electrical and Computer Engineering, who led the research.

The team developed a new technology that uses tiny smart devices known as spin-torque oscillators (STOs), which can harvest and convert wireless radio waves into power for devices. They showed that these devices can successfully harvest energy from WiFi signals and that they could generate enough energy to power a light-emitting diode (LED) wirelessly, without using a battery.

STOs are devices that can receive radio signals and transform them into microwaves. Although that sounds amazing, they’re still an emerging technology, and are still quite inefficient at their job. Currently, STOs are only able to output low levels of power.

One workaround we’re using right now is to stack several STOs together, but this isn’t always viable: many devices have spatial constraints because nobody likes chunky items. Individual STOs are also limited in the range of frequencies they can react to, generally limited to only a few hundred MHz, which further complicates their use.

The team’s solution was to use an array of eight STOs connected in a series. This was then used to convert the 2.4 GHz electromagnetic radio waves used by WiFi into a direct voltage signal (electrical current), fed to a capacitor, and used to light a 1.6-volt LED. Five seconds of charging time on the capacitor was enough to keep the LED lit for one minute with the wireless power switched off.

As part of the research, they also performed a comparison between the STOs series design they used and a parallel design. The latter, they explain, has better time-domain stability, spectral noise behavior, and control over impedance mismatch — or, more to the point for us laymen, it’s better for wireless transmission. The series layout is more efficient at harvesting energy.

“Aside from coming up with an STO array for wireless transmission and energy harvesting, our work also demonstrated control over the synchronising state of coupled STOs using injection locking from an external radio-frequency source,” explains Dr Raghav Sharma, the first author of the paper.

“These results are important for prospective applications of synchronised STOs, such as fast-speed neuromorphic computing.”

In the future, the team plans to increase the number of STOs in their array, and test it for wirelessly charging other devices and sensors. They also hope to get interest from industry in developing on-chip STOs for self-sustained smart systems.

The paper “Electrically connected spin-torque oscillators array for 2.4 GHz WiFi band transmission and energy harvesting” has been published in the journal Nature Communications.

Bio-compatible wireless sensors developed to monitor brain injury

An international research team has developed miniaturized devices to monitor living brain tissue. When no longer needed the devices can be deactivated to dissolve and be reabsorbed into the soft tissue. The wireless sensors were implanted into mice brains and successfully took intracranial pressure and temperature readings.

Dissolvable brain implant consisting of pressure and temperature sensors (bottom right) connected to a wireless transmitter. Image via theguardian

Dissolvable brain implant consisting of pressure and temperature sensors (bottom right) connected to a wireless transmitter. Kang et al, 2017

Electronic implants have long been used in the treatment of medical conditions. Ranging from the humble pacemakers and defibrillators given to cardiac patients all the way to futuristic brain-computer interfaces or injectable meshes that fuse with your brain, it’s hard to imagine today’s medical field without these devices.

Whether implanted permanently or only for short periods of time, the procedure always carries some risk — the devices can hurt surrounding tissues during implantation and their metallic components are prime real estate for bacteria, possibly leading to infections in the area. Not to mention the added risk and distress involved in removing these devices.

The novel device, developed by a research team with members from America and South Korea, is described in the journal Nature and could potentially overcome these limitations. Each device houses a pressure and a temperature sensor, each one smaller than a grain of rice. They’re housed in a biodegradable silicone chip that rests on the brain and sends data via wireless transmitters attached to the outside of the skull.

The devices were successfully tested on live rats and recorded pressure and temperature changes that occurred as the animals drifted in and out of consciousness under anesthesia. They proved to be at least as or more accurate than other devices currently available.

The team showed that by tweaking the sensors they could take measurements either from the surface of the brain up to about 5mm below it. The researchers say the device can easily be modified to monitor a wide range of other important physiological parameters of brain function, such as acidity and the motion of fluids. It could also be used to deliver drugs to the brain, and, with the incorporation of microelectrodes, to stimulate or record neuronal activity.

However, what truly makes this sensor unique is the materials that go into building them, the so-called “green electronics.” These materials are designed to be stable for a few weeks then dissolve. If immersed in watery fluids (such as cerebrospinal fluid) these fully biodegradable and bio-compatible materials take about a day to fully dissipate. When the team examined the animal’s brains after the tests, they found no indication of inflammation or scarring around the implantation site.

As well as being safer for the patient the fabrication process is also cheaper and more environmentally-friendly than that employed in existing technologies.

The next step in development is to test the devices in human clinical trials, the researchers said.

The full paper describing these devices is available online in the journal Nature.

Wireless implants can block or induce the sensation of pain

Researchers at the Washington University School of Medicine, St. Louis and University of Illinois at Urbana-Champaign have developed implantable devices that can activate — and in theory, block too — pain signals traveling from the body through the spinal cord before they reach the brain.

The devices are controlled through wireless technology and have huge application in the treatment of chronic pain in parts of the body that don’t respond to other types of treatment. The full study has been published in the journal Nature Biotechnology.

Implanted microLED devices light up, activating peripheral nerve cells in mice.
Image via phys

“Our eventual goal is to use this technology to treat pain in very specific locations by providing a kind of ‘switch’ to turn off the pain signals long before they reach the brain,” said co-senior author Robert W. Gereau IV, PhD, the Dr. Seymour and Rose T. Brown Professor of Anesthesiology and director of the Washington University Pain Center.

The devices are soft and stretchable so they can be implanted into any part of the body, Gereau explains. Previously, similar devices had to be anchored to bone tissue and proved problematic with limbs or other movable body parts.

“But when we’re studying neurons in the spinal cord or in other areas outside of the central nervous system, we need stretchable implants that don’t require anchoring,” he said.

The implants are sutured in place, and each boasts a microLED light that can activate specific neurons. The team behind them hopes to use the implants to blunt pain signals in patients who have pain that cannot be managed with standard therapies.

Experiments with genetically engineered mice (that were given light-sensitive proteins in some of their nerve cells) showed great promise for the devices. To demonstrate that the implants could influence the pain pathway in nerve cells, researchers induced a pain response. The mice were placed in a maze and as they walked through a specific area, the devices lit up and caused the little rodents to feel discomfort. When they left the area, the devices turned off, and the animals quickly learned to avoid the pain inducing part of the maze.

The experiment would have been very difficult with older optogenetic devices, which are tethered to a power source and can inhibit the movement of the mice.

As the new devices are smaller than those previously available, flexible and can be sutured in place, they have potential uses bladder, stomach, intestines, heart or other organs.

“They provide unique, biocompatible platforms for wireless delivery of light to virtually any targeted organ in the body,” he said.

Rogers and Gereau designed the implants with an eye toward manufacturing processes that would allow for mass production so the devices could be available to other researchers. Gereau, Rogers and Michael R. Bruchas, PhD, associate professor of anesthesiology at Washington University, have launched a company called NeuroLux to aid in that goal.

Facebook’s Aquila will bring solar-powered internet to regions not yet connected

This giant, solar-powered, internet giving drone is ready to take to the skies.

By far the most awesome router.
Image via foxnews

Facebook recently unveiled the Aquila, a V-wing flying drone with the wingspan of a Boeing 737 ( almost 93 ft/28.35 m ), which the media giant plans to use to connect developing regions around the world to the internet, and gather a huge amount of likes in the meantime. As there are currently an estimated 5 billion people that don’t have any way to access the world wide web, Facebook hopes the Aquila will be its key to tap into a huge and lucrative market.

Huge but light

The Aquila is quite large – huge compared to other drones – it is quite light, only weighing between 880 and 1,100 pounds ( 400 to 500 kilograms ) as the craft is meant to reach extremely high altitudes, above commercial planes and much of the cloud cover.

Beaming down Internet!
Image via alphr

“I’m excited to announce we’ve completed construction of our first full scale aircraft, Aquila, as part of our Internet.org effort,” Zuckerberg wrote. “Aquila is a solar powered unmanned plane that beams down Internet connectivity from the sky. It has the wingspan of a Boeing 737, but weighs less than a car and can stay in the air for months at a time.”

“When deployed, it will be able to circle a remote region for up to 90 days, beaming connectivity down to people from an altitude of 60,000 to 90,000 [feet],” according to Facebook.

In order to conserve energy, the plane will lower its altitude at night when sunlight is not available to power the planes.

And it has lasers

In regions without Internet access, ground-based lasers will pinpoint the location of the nearest Aquila. The craft will move towards the signal, then determine the specific location based on the laser signal. Because the Aquila depends on laser communication via the sky, Internet service can become slow and patchy in bad weather weather.

But Facebook is making great progress with lasers. The company has tested a system that delivers data at the speed of dozens of gigabytes per second, much higher than the current technology in use can deliver.

“We’ve also made a breakthrough in laser communications technology. We’ve successfully tested a new laser that can transmit data at 10 gigabits per second. That’s ten times faster than any previous system, and it can accurately connect with a point the size of a dime from more than 10 miles away.”

The Aquila drones are designed to stay airborne for up to three months, far longer than the current record of two weeks. To enable such a long flight, Facebook has equipped its autonomous plane with solar panels, which cover the top of the plane’s body. The company hopes that this longevity will allow for the creation of a resilient network of Internet-transmitting planes. In partnership with local carriers, the Aquila could play an important role in finally opening the world wide web to the whole wide world.


This five-cell metamaterial converts stray microwave energy, as from a WiFi hub, into more than 7 volts of electricity with an efficiency of 36.8 percent—comparable to a solar cell. (c) Duke University

Microwave harvester converts wireless energy into direct current with solar cell-like efficiency

This five-cell metamaterial converts stray microwave energy, as from a WiFi hub, into more than 7 volts of electricity with an efficiency of 36.8 percent—comparable to a solar cell. (c) Duke University

This five-cell metamaterial converts stray microwave energy, as from a WiFi hub, into more than 7 volts of electricity with an efficiency of 36.8 percent—comparable to a solar cell. (c) Duke University

Using a range of cheap materials arranged in a specific manner, researchers at Duke University have demonstrated a device that captures microwave signals, such as those relayed by WiFi or even satellites high up above in Earth’s orbit, an converts this free, lost energy into electrical current. The harvesting and conversion efficiency of the device is on par with currently photo-voltaic solar panels. In the future, such circuits could be used to always wirelessly power your phone when it’s not in use or charge a battery in your home.

It’s enough to open  your notebook just about anywhere downtown in a developed city to spot tens and tens of public WiFi hotspots. There are maybe tens of thousands of WiFi networks in a developed city, and all of these waste energy by constantly relaying microwave signals. The same applies to satellites, sound signals and other sources. What if you could harvest and cut the waste a bit?

This is what the Duke team of engineers, comprised of undergraduate engineering student Allen Hawkes, working with graduate student Alexander Katko and lead investigator Steven Cummer, set out to do. Using simple materials like five fiberglass and copper energy conductors wired together on a circuit board  to form a five-cell metamaterial array. The resulting device harnesses microwave energy and converts it into direct current 7.3V electricity. For reference, your  Universal Serial Bus (USB)  charges small electronic devices with 5V, so a system coupled with the Duke metamaterial circuit could provide free charging for your mobile devices.

“We were aiming for the highest energy efficiency we could achieve,” said Hawkes. “We had been getting energy efficiency around 6 to 10 percent, but with this design we were able to dramatically improve energy conversion to 37 percent, which is comparable to what is achieved in solar cells.”

“It’s possible to use this design for a lot of different frequencies and types of energy, including vibration and sound energy harvesting,” Katko said. “Until now, a lot of work with metamaterials has been theoretical. We are showing that with a little work, these materials can be useful for consumer applications.”

Microwave harvester

Another application could be to improve the energy efficiency of appliances by wirelessly recovering power that is now lost during use.

“The properties of metamaterials allow for design flexibility not possible with ordinary devices like antennas,” said Katko. “When traditional antennas are close to each other in space they talk to each other and interfere with each other’s operation. The design process used to create our metamaterial array takes these effects into account, allowing the cells to work together.”

A metamaterial coating could be applied to the ceiling of your living room, for instance, to harvest free energy from microwaves that litter space all around us. A more interesting, and maybe more practical, application might be coating smartphones with a thin layer of mematerial directly, so your phone charges constantly with significant benefits for your battery life. It’s unclear though how much voltage a thin and small surface metamaterial circuit might provide.

“Our work demonstrates a simple and inexpensive approach to electromagnetic power harvesting,” said Cummer.  “The beauty of the design is that the basic building blocks are self-contained and additive. One can simply assemble more blocks to increase the scavenged power.”

In remote locations, like in the desert or the middle of the wilderness, a series of power-harvesting blocks could be assembled to capture the signal from a known set of satellites passing overhead. The generated power would be far from impressive, of course, but it might still be enough to power a small array of sensors, the researchers believe.

Their device and findings were reported in the journal Applied Physics Letters
